HARMONY XB4, PUSH BUTTON, METAL, PROJ BLACK, 22MM DIA, SPRING RETURN, BOOTED, UNMARKED 1NO
Turks Part:
SCDXB4BP21
Mfr Number:
XB4BP21
Barcode:
3389110886993
Please LogIn
To view pricing, availability and special offers, click the button below and login.
Contact your local branch for availability.
Supplier Packages :
Package options may not always be available
Package Options
Number of items
1 Box
5 EAC
EAC
Min: 1 EAC
Technical Documents
Technical Documents
Product Details
Product Details
This Harmony XB4 modular black push button operates with a spring return / impulse MECHANISM It has a metal bezel This push button provides a simple and robust control to machines and processes It is easily installed into sta
This Schneider Electric Harmony XB4 modular black push-button operates with a spring return / impulse mechanism and uses screw clamp terminals. It has 1 x NO contact and a chromium-plated metal bezel with a clear silicone boot. This push-button provides a simple and robust control to machines and processes. It is easily installed into standard 22 mm diameter cut-outs and connected with simple screw-clamp connections. Its schematic is clearly distinguishable thanks to clear colors and markings, minimizing errors during initial wiring and later maintenance operations. It is impact resistant, dust proof, waterproof and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K, making it ideal for operation in harsh environments.
This Schneider Electric Harmony XB4 modular black push-button operates with a spring return / impulse mechanism and uses screw clamp terminals. It has 1 x NO contact and a chromium-plated metal bezel with a clear silicone boot. This push-button provides a simple and robust control to machines and processes. It is easily installed into standard 22 mm diameter cut-outs and connected with simple screw-clamp connections. Its schematic is clearly distinguishable thanks to clear colors and markings, minimizing errors during initial wiring and later maintenance operations. It is impact resistant, dust proof, waterproof and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K, making it ideal for operation in harsh environments.
Technical Specifications
Technical Specifications
Does this product not have all the features you are looking for?
Please don't hesitate to conduct a search for other products with similar technical specifications.
To find similar products, please select the desired specifications from the white boxes below.
To help with your selection, try selecting the Select All button below then deselect any unwanted specification.
Please select at least 1 attribute to search.
Push button, complete |
|
| Number of contacts as normally open contact |
1
|
|---|---|
| Degree of protection (NEMA) |
4X
|
| Number of command positions |
1
|
| Colour front ring |
Chrome
|
| Width opening |
0 mm
|
| Number of contacts as change-over contact |
0
|
| Material front ring |
Metal
|
| Type of button |
High
|
| Spring-return |
Yes
|
| Suitable for illumination |
No
|
| Type of electric connection |
Screw connection
|
| Transparent |
No
|
|---|---|
| Colour button |
Black
|
| Construction type lens |
Round
|
| With front ring |
Yes
|
| Supply voltage lamp |
0 V
|
| Degree of protection (IP) |
IP66
|
| Hole diameter |
22.5 mm
|
| Height opening |
0 mm
|
| Switching function latching |
No
|
| Number of contacts as normally closed contact |
0
|
